| Provider Mode Ports |
| Fixed Port |
2*1000 Base-X, 4*10/100/1000Base-T (POE & POE+ Support) |
| Power interface |
Redundant dual power supply (Solar & Battery) |
| LED Indicators |
PWR, Link, ACT LED |
| Protection |
IP40 rated protection, 8-15KV anti-static and 4KV surge protection |
| Dialing instructions |
| 1. LFP |
Remote PD restart |
| 2. LGY |
LEGACY (Standard/Non-Standard POE) |
| 3. VLAN |
Port Isolation |
| 4. RST |
Reset |
| Network Topology |
| Star topology, Bus topology & Tree topology |
Support |
| Electrical Specifications |
| Input voltage |
DC12-58V (Non-PoE), DC48-58V (PoE) |
| Total Power consumption |
<5W (Non-PoE), <125W (PoE) |
| PoE |
| PoE port |
1~4 |
| PoE Protocol |
802.3af, 802.3at |
| Pin Assignment |
1,2,3,6 |
| Layer 2 Switching |
| Switching capacity |
14G |
| Packet forwarding rate |
10.416Mpps |
| MAC address table |
8K |
| Buffer |
1M |
| MDIX/MDIX, Flow control, Port Isolation, Remote PD restart, and Reset |
Support |
| Jumbo Frame |
Support 10K bytes |
| Power |
| Solar Panel Input capacity |
Up to 550W with 12V DC Supply |
| Battery |
Up to 150Ah Battery |
| DC Power |
48V DC & 12V DC Available |
| USB |
1 USB Ports |
| Protection |
Surge protection up to 80KA (No external earthing required) |
| Protection on POE Ports (4 Ports) |
4KV Surge protection on each POE Ports |
| Mechanical |
| Outer Box |
IP 66 Box for outdoor Application |
| Mounting options/Installation Method |
Pole Mounted, Wall Mounted and Table mounted (Mounting accessories including) |
| Lock |
Physical Lock and mechanical lock options |
| Environment |
| Operating temperature and Storage temperature |
-30°C ~ +60°C |
| Relative humidity |
5%~95% non-condensing |
| MTBF |
100,000 hours |
| Protection parameter (without external/Ground earthing) |
| Maximum surge handling capacity |
120 kA (8/20 micro seconds) |
| Short circuit withstand current |
10kA |
| Residual current |
0.001 amps |
| Spark over voltage (8/20µS) |
1.5kV |
| Impulse Response Time |
<25 Nano Second |
| Max. Leakage Current at 75% V1mA, IL (µA) |
20 µA |
| Protection on POE Ports (4 Ports) |
4KV Surge protection on each POE Ports |
| 165W Solar Panel Specifications |
| Maximum Power (Pmax) |
165 watt |
| Maximum Voltage (Vmax) |
19.47 V |
| Maximum Current (Imax) |
8.48 A |
| Open Circuit Voltage (Voc) |
23.45 V |
| Short Circuit Current (Isc) |
8.98 A |
| Maximum System Voltage |
600 VDC |
| Module Eff. (%) |
21.14% |
| Fuse Rating |
25 A |
| Tolerance |
±2% |
| Module Size |
1495*675*30mm |
| Glass Size |
1490*670*2.8mm (ARC) |
| Solar Cell |
36 Poly Cell (157*157mm) |
| Weight |
10.6 Kg |
| Junction Box |
2 Rail JB (IP68) |
| Cable & Connectors |
MC4 Connectors (4mm²) |
| AL Frame |
Anodised AL Frame |
| Mechanical load test |
2400 Pa (Snow Load) 1600 Pa (Wind Load) |
| Application Class |
Class A |
| Fire Safety |
Class C |
| Wind Mill Specifications |
| Rated power |
300W |
| Maximum power |
300W |
| Rated voltage |
12/24V |
| Start-up wind speed |
2 m/s |
| Rated wind speed |
14 m/s |
| Cut-in wind speed |
3.5 m/s |
| Number of blades |
5 pieces |
| Body material |
nylon fiber |
| Generator |
three phase AC permanent magnet generator/maglev generator |
| Control system |
electromagnetic brake |
| Yaw mode |
automatic windward angle |
| Lubrication mode |
self lubrication |
| Tower form |
guyed tower/independent tower |
| Working temperature |
-40°C~80°C |
